Condux 08960450 4/0 AWG Green Clevis Head Reusable Power Pulling Eye

Product Description

INCLUDES:
• (1) Clevis Socket
• (1) Sleeve Nut
• (1) Plug

FEATURES:
• Slotted Head with Clevis Pin
• Will fit the 1/8" (3 mm) and 1/4" (6 mm) cable pulling harnesses

SPECIFICATIONS:
• Part Number: 08960450
• Cable Size: 4/0 AWG
• Color: Green
• Maximum Conductor Diameter: .528 in. (13 mm)
• Max Eye OD (A): 1.00 in. (25 mm)
• Slot Width (B): .38 in. (10 mm)
• Slot Depth (C): 1.06 in. (27 mm)
• Pin Diameter (D): .31 in. (8 mm)
• Pin Center (E): .53 in. (13 mm)
• Replacement Plug Part Number: 08960423
• Load Rating: 2500 lbs (1134 kg)


The Clevis Head Power Pulling Eyes feature a slotted head with clevis pin to allow direct attachment to the Condux multiple pulling harness. When pulling multiple cables into a single conduit, the conductors can be attached to a harness and installation is simplified to a single pull of one assembly. Each Clevis Head Power Pulling Eye includes a clevis socket, sleeve nut, and plug.
